Drum seeding line LAMBDA65: can reach a production up to 650 trays/hour.
The trayfiller ensuring the maximum filling uniformity in every cell; the driven dibbler ensures a centered positioning in the cell and a perfectly regular shape of the hole; complete the line the drum coverer, the watering unit with drilled bars and the pneumatic balance stacker. Equipped with a SINGLE seeding drum.
Soil hopper capacity 600 l with agitator; soil elevator with cups-system width 470 mm with double chain; recycling hopper for exceeding soil with auger INCLUDED; longitudinal tray advancement; rapid adjustment of tray width with self-centering handles INCLUDED; watering units length 250 mm with 2 drilled bars; 5,7” colour touch-screen panel.
| TECHNICAL DATA | M.U. | YPSILON65 | YPSILON65 A | YPSILON65 E |
|---|---|---|---|---|
| HOURLY PRODUCTION (Min-Max) | trays/hour | 650 | 600 | 600 |
| DIMENSIONS of TRAYS (max) | mm | 580×400 | 750×400 | 750×500 |
| WEIGHT | kg | 1350 | 1350 | 1350 |
| VACUUM PUMP | model | PVA 750 | PVA 750 | PVA 750 |
| CONSUMPTION of AIR (max) | l/min | 190 | 190 | 190 |
| CONSUMPTION of WATER to 2 atm (max) | l/min | 20 | 20 | 20 |
| POWER of INSTALLATION | kW | 8 | 8 | 8 |
